HDA-170 Air cushion machine

Share to:
  • HDA-170

Features:

1. Portable design&easy operation.

2. Well sealed without air leakage.

3. Air,temperature,speed adjustable

4. Logo print available on film,build up your own logo

5. One machine can work with all different size,type film.

Machine will work automatically once the temperature up to setting temperature

Technical date:

Model

HDA-170

Speed

0-18 M/Min(Adjustment)

Air volume

0-300L/Min(Adjustment)

Sealing temperature

160-220(Adjustment)

Net weight

6.4KG

Gross weight

8.0KG

Power

250W

Power supply

110/220V  50/60HZ 1PH

Machine dimension

L430*W120*H310MM

Package dimension

L510*W390*H420MM

Application Film

HDPE Film

Roll size

Core51MM*D220MM

Suitable film size

T20-40micron*W100-600MM

Film specification

Core

Thickness

Width

Diameter

51mm

20-40micron

600MM(MAX)

220mm

Scope:

Air cushion machine is perfect choice for e-commerce, express logistics, printing supplies industry, ceramics and cosmetics, handbag and luggage, electronic products, automobile parts, fruit.

Description:

HDA-160 is an economic, simple operation and portable device for inflated air. A multi-purpose all-in-one on-demand machine with beautiful appearance that can be inflated for air pillow,air bubble, air column, air beehive,air wave,air bubble bag.Machine sealing more neat and dense, less noise, longer service life compared with other competitors. Simple interface, according to the different bag characteristics to adjust the temperature, air and speed. It is the best choice for small factories, warehouses and shops.

What our machine can do:



图片 6图片 9图片 7图片 8
